The Skyeye 5000 VTOL UAV Platform is an advanced unmanned aerial vehicle designed to meet the rigorous demands of professional aerial missions. Featuring a remarkable 5000mm wingspan and state-of-the-art vertical take-off and landing (VTOL) capabilities, this UAV platform offers unparalleled performance, flexibility, and reliability. Crafted from full carbon fiber, the Skyeye 5000 VTOL drone is lightweight yet exceptionally durable, ensuring long-term operational efficiency.
The Skyeye 5000 VTOL UAV platform is an airframe that, when equipped with a suitable power system, can achieve flight times exceeding 8 hours. One of our clients even achieved with a flight time of 12 hours. Its impressive endurance and high payload capacity make it ideal for a variety of applications. With a maximum payload capacity of 25 kg, the Skyeye 5000 VTOL drone is perfect for long-range material delivery and transport, aerial surveying and mapping, environmental monitoring, precision agriculture, search and rescue operations, and infrastructure inspection. The platform’s robust payload bay can accommodate various sensors and equipment, tailored to specific operational needs.
Key features of the Skyeye 5000 VTOL drone include its VTOL capability, which eliminates the need for runways, allowing it to operate in confined spaces and challenging terrains. This versatility makes it suitable for diverse applications, from remote material delivery to environmental monitoring. The full carbon fiber construction ensures resilience against harsh conditions and reduces maintenance needs, enhancing long-term reliability.
We recommend to use 17x 6s 8000mAh or 10000mAh batteries. 4x batteries are connected in series to be used as 24s. A total of 4 sets of batteries supply power to the 4 VTOL motors, and the remaining one battery supplies power to the engine and other electronics.
| PARAMETER | Wingspan | 5000mm |
| Length | 3500mm | |
| Maximum Width of Fuselage | 375mm | |
| Wing Area | 261.5 dm2 | |
| Airframe Material | Full carbon fiber | |
| Weight and Payload | Empty Weight | 34kg |
| Take-off Weight | 100kg | |
| Payload Capacity | Up to 25kg | |
| Volume of Fuel Tank | 28Liters | |
| Equipment cabin size | 1000mm x 340mm x 350mm | |
| Flight Characteristics | Endurance | Over 8 hours (max. 12 hours as per one client’s feedback) |
| Maximum Speed | 38m/s | |
| Cruise Speed | 35m/s | |
| Stalling Speed | 24m/s | |
| Range | 800km | |
| Packaging Information | Wing section | 190*50*80cm |
| Fuselage section | 190*50*48cm |
| Skyeye Wingspan 5000MM | |||
| Name | Specification | KIT | PNP |
| Flying platform | SV500 Outer wing | 2 | 2 |
| SV500 Center wing | 1 | 1 | |
| SV500 Main body | 1 | 1 | |
| SV500 undercarriage | 1 | 1 | |
| SV500 Plain tail | 1 | 1 | |
| SV500 Stern stay | 2 | 2 | |
| SV500 Front stay | 2 | 2 | |
| SV500 hatchcover | 1 | 1 | |
| SV500 Fuel tank | 1 | 1 | |
| SV500 Engine hood | 1 | 1 | |
| Power system | DLE 222cc Engine | 1 | |
| T-motor V13L KV65 VTOL Motors | 4 | ||
| T-motor THUNDER 200A 24S ESC | 4 | ||
| Pilot PW-48AH Servo | 2 | ||
| Pilot PW-28AH Servo | 4 | ||
| Tower Pro MG958 Servo | 2 | ||
| Sail 32x12 High Power Propeller | 1 | ||
| T-motor V40*16-Prop-2PCS/PAIR | 2 | ||
| MT90 UAV Pitot Tube | 1 | ||
| Wire bale | 1 | ||
Information Updated version:2202412311519
If the product exceeds the maximum order weight of the system, the logistics cost can consult our customer service staff.
Note:
Production lead time: 7-15 working days (ask customer service about production schedule before ordering)
The shipping time is expected to be another 7~14 days
Prices and freight are for reference only, no stock, orders need to wait for production time.
