Material: EPO, EVA, carbon fiber,engineering plastics, etc.
Wingspan: 2100mm
Max. takeoff weight: <7.5kg
Rotor arm:744mm
Maximum takeoff altitude: 3000m(altitude)
Fuselage height: 156mm (without foot pads)
Practical lift altitude: 4500m(altitude)
Fuselage length:1200mm
Wind resistance: Class 5(normal operation)
Wing area: 59dm²
Takeoff mode: vertical takeoff and landing
Cruising speed: 18-21m/s
Load compartment size:180x150x110mm
Maximum load: 1kg
Transport box size: 1.08x0.35x0.48m
Stall speed:10m/s
Disassembly and assembly method: tool-less quick disassembly
4+1 range performance:
82min/95km(speed 19m/s load 600g, battery 6S@16000mah, take-off weight 6.5kg, alti-tude 500m)
4+1 range performance:
112min/127km(speed 19m/s load 600g, battery 6S@22000mah, take-off weight 7.lkg.altitude 500m)
4+2 range performance:
96min/105km (speed 19m/s load 600g, battery 6S@22000mah, take-off weight 7.3kg, al-titude 500m)
NOTE:
1、”Power System" means only power parts, not the aircraft fuselage
2、If you are failed to place order directly from our web shop, pls contact our sales team to get support.
Download:User Manual
