Material: EPO,EVA,carbon fiber,PC,engineering plastics and etc.
Wing Span:2430mm
Fuselage height: 180mm
Fuselage length:1450mm
Suggested fight speed:19-20m/s
Maximum payload: 1.5Kg
Longest flight range: >150km(600g load)
Practical ceiling height: 4000m
Take-off and landing approach: VTOL
Wing area:72.5dm2
Stalling speed: 10m/s
Payload cabin size:280*160*110mm
Max take-off weight:11.5kg
Wind resistance: 5
Dismounting way: tool-free
Transport case seize:1.25mx0.34mx0.49m
Range 1:120min/137km(speed 19m/s load 600g,battery 2pcs 6s 16000mah in series,take-off weight 10KG,altitude 500m)
Range 2:134min/155km(speed 19m/s,load 600g,battery 2pcs 6S 22000mah in series,take-off weight 11.2KG,altitude 500m)
NOTE:
1、”Power System" means only power parts, not the aircraft fuselage
2、If you are failed to place order directly from our web shop, pls contact our sales team to get support.
Download:User manual
