NOTE:
1、”Power System" means only power parts, not the aircraft fuselage
2、If you are failed to place order directly from our web shop, pls contact our sales team to get support.
Download
User Manual
Description:
Test Data:
| 4S Test Power Configuration | 6S Test Power Configuration | ||
| Species | Model | Model | Quantity |
| Motor | Sunnysky 2814 KV900 | LDPOWER 2814 KV510 | 2 |
| ESC | Hobbywing X-Rotor 40A | Hobbywing X-Rotor 40A | 2 |
| Servo | Emax ES3154 | Emax ES3154 | 4 |
| Propeller | APC1145 CW&CCW | APC1145 CW&CCW | 1 Pair |
| Battery | 4S 20000mAh | 6S 16000mAh | 1 |
| Max. Pull | About 4.5kg | About 4.5kg | |
| Load Weight | a6000(440g) | a7r(670g) | 1 |
| Take-off Weight | About 4.2kg(included load 440g) | About 4.5kg(included load 670g) | |
| Endurance | About 80km | About 90km | |
| Test Conditions | Altitude: 470m Wind Speed: Level 3 | ||
